Product/Service Description
4K, Dual Display, HDMI KVM Extender over Single Fiber Cable, 4K @ 20KM, USB 2.0, Audio, RS-232 Extender, FBVVMS-M02K-20, Allows Extension of a Dual-Monitor PC with 4K@30Hz Resolution and USB 2.0.
Single-Wire Fiber Allows FBVVMS-M02K-20 to Deliver Dual Videos over a Single Duplex Fiber Cable. The System Installation Can Be Easier, and the User Can Save the Cost of Tens of Kilometers of Cables.
Dual USB Allows FBVVMS-M02K-20 to Work with KVM Switch Application.
Traditional KVM Extenders Have Only One USB Channel, Which Is Bound to the USB Console, and with This Dual-USB Topology, the Extra USB Channel Can Be Used for USB 2.0 Extension ( USB Devices ).
Hybrid Video Model, FBVVBS-M12K, Has One HDMI Signal Input and One DP Signal Input. This Is Designed for Modern Graphic Cards, Which Has One HDMI and Multiple DP Outputs.
Features:
”½ Single-Wire ( cSFP ) Allows Remote Access to a Dual Display Computer Up to 20KM by Transmitting 2 Video Streams over a Duplex Fiber Cable
”½ Dual-Monitor Supports Most Popular Resolutions Up to 4K@30Hz
”½ Dual USB Extension Provides 2 USB Extension Channels, One for K/M Control and the Other for USB 2.0 Devices ( Perfect for KVM Switch )
”½ Dual Audio Extension Provides 2 Audio Extension Channels, One for Audio Embed / Extract and the Other for Independent Audio Extension
”½ IR Extension from Console Unit to Computer Unit Facilitates IR Control
”½ Serial Extension with Selectable Baud Rate
”½ HDCP Compliance Ensures Uninterrupted HDCP Video Playback
”½ Supports Windows / MAC / Linux / Chrome O.S...
”½ New FBVVBS-M12K, HDMI + DisplayPort Hybrid Video Inputs, Also Available
Single-Wire Fiber Allows FBVVMS-M02K-20 to Deliver Dual Videos over a Single Duplex Fiber Cable. The System Installation Can Be Easier, and the User Can Save the Cost of Tens of Kilometers of Cables.
Dual USB Allows FBVVMS-M02K-20 to Work with KVM Switch Application.
Traditional KVM Extenders Have Only One USB Channel, Which Is Bound to the USB Console, and with This Dual-USB Topology, the Extra USB Channel Can Be Used for USB 2.0 Extension ( USB Devices ).
Hybrid Video Model, FBVVBS-M12K, Has One HDMI Signal Input and One DP Signal Input. This Is Designed for Modern Graphic Cards, Which Has One HDMI and Multiple DP Outputs.
Features:
”½ Single-Wire ( cSFP ) Allows Remote Access to a Dual Display Computer Up to 20KM by Transmitting 2 Video Streams over a Duplex Fiber Cable
”½ Dual-Monitor Supports Most Popular Resolutions Up to 4K@30Hz
”½ Dual USB Extension Provides 2 USB Extension Channels, One for K/M Control and the Other for USB 2.0 Devices ( Perfect for KVM Switch )
”½ Dual Audio Extension Provides 2 Audio Extension Channels, One for Audio Embed / Extract and the Other for Independent Audio Extension
”½ IR Extension from Console Unit to Computer Unit Facilitates IR Control
”½ Serial Extension with Selectable Baud Rate
”½ HDCP Compliance Ensures Uninterrupted HDCP Video Playback
”½ Supports Windows / MAC / Linux / Chrome O.S...
”½ New FBVVBS-M12K, HDMI + DisplayPort Hybrid Video Inputs, Also Available
